Now the world's most technologically advanced winch - the ZEON Platinum™ - comes in a 12,000 pound capacity version spooled with extra-strong Spydura® Pro synthetic rope. Already packed with performance features, ZEON Platinum 12-S features the Advanced Wireless Remote that puts winch, clutch and accessory control in the palm of your hand. And now, with the addition of Spydura Pro, you can really see what it means to be winching's top dog.
All-new high-speed motor, stronger gears, and heat-treated ring gear deliver 20% faster line speed, best-in-class efficiency, and our highest durability rating.
The Advanced Wireless Remote gives you total control in the palm of your hand, allowing you to control the winch and up to two accessories. This sophisticated, advanced remote provides operator feedback on vehicle battery charge and winch motor temperature, controls operation of the winch clutch, and more. Includes USB charging cable and car charger adapter.
Remote Controlled Clutch is engaged and disengaged with the Advanced Wireless Remote. The remote controls winch-in, winchout, and freespool operations. No more engaging a manual clutch, with frozen fingers while standing in the mud.
Durable aluminum structure with flat black powder-coated finish and stainless steel fasteners delivers durability and maximum corrosion resistance-exceeding 400 hours of salt-spray testing.
Large diameter alloy winch drum with steel sleeve is strong, light weight, reduces rope wear, and has an integrated rope anchor for easy rope installation.
Extreme waterproofing meets rigorous IP68 standards - the highest rating in the WARN Truck/SUV winch lineup.
Convertible control pack can be attached to the winch or remotely mounted, allowing for various winch mounting options and looks (Relocation kit required and sold separately). The new-style control pack with contactor and advanced controls gives you extreme reliability and weather resistance.
Limited Lifetime Warranty
TYPE
Electric
MOUNT TYPE
Vehicle Mounted
RECOMMENDED USE
Vehicle Recovery
VOLTAGE
12 Volt
ELECTRICAL CONTROL TYPE
Contactors
MOTOR TYPE
Series Wound
THERMAL SHUTOFF
No
DRIVE GEAR TYPE
Planetary
GEAR REDUCTION RATIO
216:1
FREE SPOOLING
Yes
BRAKE TYPE
Mechanical Cone
LINE DIAMETER (IN)
3/8 Inch
LINE LENGTH (FT)
80 Feet
LINE MATERIAL
Steel
FAIRLEAD TYPE
Roller
CONFORMS TO J706 STANDARDS
No
REMOTE TYPE
Wireless
MOUNTING HOLE QUANTITY
4
OPERATION TYPE
Automatic
MOUNTING PATTERN LENGTH (IN)
12 Inch
MOUNTING PATTERN WIDTH (IN)
4-1/2 Inch
INCLUDES MOUNTING HARDWARE
Yes
COLOR
Black
DRUM MATERIAL
Aluminum
MAX AMP DRAW/ LINE PULL
446 Amp Draw/ 12000 Pound
MAX LINE PULL/ LINE SPEED
12000 Pound/ 4.5 Feet Per Minute
WARN ZEON 12 PLATINUM Winch 12V (92820) - Features
Fitment
ALL
UPCCode
012748048046
Box Height
8.25 in
Box Width
20 in
Box Weight
106 lbs
Brand
Warn
Line Material
Steel
Winch Fairlead Type
Roller
Drum Material
Aluminum
Winch Gear Ratio
216:1
Winch Line Length
80 ft.
Winch Rated Line Pull
12000 lbs.
Winch Type
Electric
Remote control
Wireless
